Model NO.

TP-630A-M10

TP-630A-M13

TP-630A-M20

TP-630A-M30

TP-630A-M50

Camera

Image Sensor

OV9732

Aptina 0130

Sony 323

Aptina 0330

Sony 326

Image Resolution

1.0MP

1.3MP

2.0MP

3.0MP

5MP

Effective Pixels

1280x720

1280x960

1920*1080

2048*1536

2592*1920P

TV System

PAL/NTSC

Electronic Shutter

1/25s~1/50,000s , 1/30s~1/60,000s

Sync System

Internal

Usable Illumination

0.01Lux

0.001Lux

0.001Lux

0.001Lux

0.001Lux

S/N Ratio

50dB

Scanning System

Progressive Scan

Video Output Mode

AHD/CVBS (960H) (BNC)

Lens

Focus Length

3.6mm

Focus Control

Fixed

Night Vision

Infrared LED

36pcs Leds

Infrared Distance

20M

IR Status

Under 10 Lux by CDS

IR Power On

CDS Auto Control

Camera Features

Day/Night

Auto / Color / B&W

EN, CN, DE, FRA, IT, ES, PL, RU, PT, NL, TR

White Balance

Auto/Manual

Gain Control

Auto

Noise Reduction

3D NR

Picture Adjustment

Yes

OSD Support

Yes

General

Weatherproof Housing

YES, Metal

Anti-cut Bracket

YES

Dual Voltage

NO

IR Cut Filter

YES

Heater

NO

Operation Temperature

-10 ~ +50 RH95% Max

Storage Temperature

-20 ~ +60 RH95% Max

Power Source

DC12V10%, 500mA

Dimension

85*65mm

Weight

600g
