Features:
1/2.9" Sony Exmor CMOS sensor, Full HD resolution 1920 x 1080P
Ultra low illumination 0.01Lux
10x optical zoom, PTZ control
Day/Night (ICR), AWB, AGC, BLC, 2D/3D-DNR,WDR, Smart IR, Motion Detection, Privacy Mask, Mirror
Lightning protection 4000V
Strong water-proof housing, IP66
4 pcs Array IR Leds, IR distance 60-80 meters, 2.4-12mm AF lens
Model |
TP-IP200IR-4X |
Camera |
Image Sensor |
1/2.9" Sony Exmor CMOS |
Effective Pixels |
1920(H)1080 (V) |
Electronic Shutter |
AUTO, 1/25s ~ 1/100000s |
Min. Illumination |
0.01Lux@F1.6(AGC ON), 0Lux IR on |
Day/Night |
Auto/Color/(B/W) |
WDR |
Digital WDR |
White Balance |
Auto |
AGC/BLC/HLC |
Support |
DNR |
2D/3D DNR, multi-levels adjustable |
OSD Menu |
Support |
Other |
Motion, Privacy Mask, Mirror, Flip |
Encode |
Embedded Solution |
Ambarella A5S |
Video Standard |
H.264 |
Video Resolution |
1080P@25/30fps |
Video Bitrates |
32Kbps - 16Mbps, VBR/CBR |
Audio Standard |
G.711-u |
IR Led |
IR Led |
4 pcs 850nm Array IR Leds |
IR Distance |
60-80 M |
Lens |
Focal length |
5.1 -51 mm AF lens |
Zoom |
10x optical zoom |
PTZ |
Pan/Tilt Range |
Pan: 0 ~ 300; Tilt: -5 ~ 60 |
Preset Point |
256 |
Manual Control Speed |
Pan: 0.5 ~12 /s; Tilt: 0.51 ~12 /s |
Preset Tour |
8 lines |
Pattern Scan |
4 lines |
Power On Action |
None/Preset/Pan can/Cruise |
Optional Function |
POE, Audio, Alarm In/Out, SD card, etc. |
Network Services |
Web |
IE , Chrome, etc. |
Media |
CMS, Android, IOS |
ONVIF |
2.0 compatible |
General |
Network Port |
1-RJ45, 100Mbps, POE optional |
Power Supply |
12V DC 10% |
Power Consumption |
< 15 W |
Operating Temp. |
-30-(+60), 10%-90%RH |
|
