FEATURES:
• Stand-Alone DVR, H.264 Compression
• High quality video Display : NTSC (720x480),
PAL (704x576) real time display
• Multiple Recording/ Search Categories:
Date/Time, Event, Manual, Schedule
120 Fps for NTSC at CIF image (100 Fps for PAL)
• 4ch Video recording at the same time
• Pentaplex: Live, Record, Playback, Back-up and Network at the same time
Network Viewer
• Static, Dynamic IP and DDNS , Support Internet Explorer and special client software
• Remote Live Monitoring, file searching, Backup, Playback
• Remote Configuration, Firmware Upgrade and Event ( Motion, Email) Notification
• Mobile monitoring (3G), Iphone
|
Model: |
7504 |
|
Channel: |
4 ch |
|
Video signal: |
PAL system (25 frames / sec)
NTSC system (30 frames / sec) |
|
Video input: |
BNC(1.0Vp-p/75)4 |
|
Video output: |
Composite Video: 1.0V pp/75, BNC connector 1 VGA 1 |
|
Network mode: |
10/100M adaptive, support LAN, WAN and ADSL dynamic IP networking |
|
Monitoring methods: |
IE monitoring, phone monitoring, |
|
Control: |
support for the mouse, remote control, |
|
Backup mode: |
support USB and Network Backup |
|
Resolution: |
PLA system: Display Resolution: 720 576 compressed resolution: 352 288
NTSC system: Display Resolution: 720 480 compressed resolution: 352 240
Playback Resolution: 1CH D1+3CH CIF |
|
Compression Standard: |
H.264 |
|
Hard disk: |
one large hard drives 2000G |
|
Security features: |
two password management |
|
Power supply: |
DC 12V/2A |
|
Power: |
6W (without hard drive) |
|
Temperature: |
Operating temperature: +5 ~ +50 ; humidity: <90%
Storage temperature: -20 ~ +70 ; humidity: <95% |
|
Dimensions: |
22044215mm(W H D) |
|
Weight: |
Net weight: 1.5Kg Gross Weight 2kg |
Back Panel
1. Video input
2. Video output
3. VGA output
4. Network
5. USB
6. Power Supply |
