TP-450V |
| |
|
|
|
TP-450V |
TP-550V |
TP-650V |
| Image Sensor |
1/3'' Sony SUPER HAD CCD |
1/3'' Sony SUPER HAD CCD |
1/3'' Sony SUPER HAD CCD |
| Effective pixels |
PAL:752(H)x582(v) |
| NTSC:768(H)x494(v) |
| Horizontal Resolution |
420 TVL |
550 TVL |
600TVL |
| Signal System |
PAL/NTSC |
| LENS |
4-9mm Manual focus auto iris lens |
| S/N Ratio |
>48dB |
| Shutter Speed |
1/50(1/60)1/100,000(Sec.) |
| White Balance |
Auto Tracking White Balance |
| Video Output |
1Vp-p,75ohm,BNC |
| Power Supply |
DC12V(when IR Leds turn on, maximum current is 1A) |
| Minimum Illumination |
0 Lux (IR LED on) |
| IR Wavelength |
850nm |
| IR Distance |
30m |
| IR Led |
42pcs 5mm IR Leds |
| Dimension |
160x84mm |
| Operating Temperature |
-20 ~ +50
| |
|
|
