SH-7918 |
| |
|
| MODEL |
SH-7917 |
SH-7918 |
| Pickup device |
1/3 Sharp CCD |
1/3 Sony CCD |
| Number of pixels |
PAL:512(H) *582(V) NTSC:512(H) *492(V) |
PAL:512(H) *582(V) NTSC:512(H) *492(V) |
|
| System of signal |
NTSC/PAL |
| Horizontal resolution |
420TV Line |
540TV Line |
| Minium illumination |
0Lux/F1.2 |
| Backlight compensation |
Auto |
| White balance |
Auto |
| Electronic shutter |
1/50(1/60)~1/100,000sec |
| Lens |
16mm，6mm/8mm/12mm(Optional) |
| S/N ratio |
>48dB |
| Gamma correction |
>0.45 |
| Operation Temperature |
-70 |
| Sync.system |
Internal |
| Video output |
1.0vp-p/75 |
| Power supply |
DC12V,1000mA |
| Wavelength |
850nm |
| Dimensions(mm) |
89(D) *162(L) 95(D)*162(L) |
| Weight(g) |
500g |
| LEDS |
36 |
| OR viwe distance |
40m |
| Waterproof Rate |
IP67 | |
|
|
