成像器件      Pickup device

1/3 Sony CCD

像素          Number of pixels

PAL:752(H)×582(V)   NTSC:752(H)×492(V)

PAL:512(H)×582(V)   NTSC:512(H)×492(V)

信号制式      System of signal

NTSC/PAL

水平解晰度    Horizontal resolution

540TV Line

480TV Line

420TV Line

最低照度      Minium illumination

0Lux/1.2<IR ON>

镜头          Lens

8mm

背光补偿      Backlight compensation

Auto

电子快门      Electronic shutter

1/50(1/60)~1/100,000sec

白平衡        White balance

Auto

信噪比        S/N ratio

>52dB

>48dB

伽玛校正      Gamma correction

>0.45

工作温度      Operation temperature

-20℃-50℃

同步方式      Sync.system

Internal

视频输出幅度  Video output

1.0Vp-p/75Ω

所需电源      Power supply

DC12V,1000mA(IR ON)

尺寸          Dimensions(mm)

310(L)×105(H) ×158(W)

红外线波长    Wavelength

850nm

重量（公克）  Weight(g)

1050g

可视距离      IR view distance

25pcs Φ10 IR LED 40-50m

防水等级      Waterproof Rate

IP66
