DOUBLE GLAZING structure, anti-fog, anti-infrared light reflection;
New alignment of integration within the stent, to prevent the wire being damaged or aging fast;
Rear external 4-9MM manual focusing, adjusting the intensity of light, but also facilitate the installation after the completion of debugging;
Low power consumption, during the day, good color reproduction, color turns black and completely;
|
MODEL |
TP-779 |
TP-773 |
|
成像器件 Pickup device |
1/3” Sony CCD image sensor |
|
像素 Number of pixels |
PAL:752(H) ×582(V) NTSC:752(H) ×492(V) |
PAL:512(H) ×582(V) NTSC:512(H) ×492(V) |
|
信号制式 System of signal |
NTSC/PAL |
|
水平解晰度 Horizontal resolution |
540TV Line |
420TV Line |
|
最低照度 Minium illumination |
0Lux/F1.2 |
|
背光补偿 Backlight compensation |
自动 Auto |
|
白平衡 White balance |
自动 Auto |
|
电子快门 Electronic shutter |
1/50(1/60)~1/100,000sec |
|
可配镜头 Lens |
4-9mm（Manual varifocal lens） |
|
信噪比 S/N ratio |
＞52dB |
＞48dB |
|
伽玛校正 Gamma correction |
＞0.45 |
|
工作温度 Operation Temperature |
-20℃ ～50℃ |
|
同步方式 Sync.system |
Internal/内同步 |
|
视频输出幅度 Video output |
1.0vp-p/75Ω |
|
所需电源 Power supply |
DC12V,800mA |
|
红外线波长 Wavelength |
850nm |
|
尺寸 Dimensions(mm) |
186(L) ×96(W) ×93(H) |
|
重量(公克) Weight(g) |
1281g |
|
红外灯数量 LEDS（pcs） |
35(φ8) |
|
可视距离 OR viwe distance |
35-50m |
|
防水等级 Waterproof Rate |
IP67 | |
